Ultra-Compact 1000 W RMS Monoblock Class D Amplifier – 1 Ω Stable | Hamilton, Auckland NZ
Powerful and compact Class D monoblock amplifier delivering up to 1000 W RMS at 1 Ω. Features LPF, subsonic filter, bass boost, MOSFET power supply. Installed in Hamilton & Auckland.
The Ultra-Compact 1000 W RMS Class D Monoblock Amplifier is engineered for maximum bass output in minimal space. Designed to deliver 1000 W RMS @ 1 Ω, this amplifier is stable across load ratings, making it perfect for high-power subwoofer systems in tight installations.
Featuring a MOSFET power supply, adjustable low pass filter (LPF), subsonic filter, bass boost, and remote gain control knob, it enables precise tuning for clean, powerful low-end performance. Built-in protection protects against over-current, thermal overload, low/high voltage, and short circuits.
POWERFUL AND VERSATILE
The DBES1000 is a very compact mono amplifier with a power of 400 Watts RMS at 4 Ohms. Specially designed for powering a subwoofer, this amplifier combines very high power and some great features. Stable at 2 Ohms and 1 Ohm, equipped with a complete range of settings for adjusting low-frequency sensitivity, a remote control and output lines, this amplifier is capable of bluffing performances. Whether it’s for powering an audiophile bass system or a powerful subwoofer, the DBES1000 will meet all your needs for your bass channel.
- – Mono Class D amplifier
- – Complete range of settings (subsonic filter, bass boost, phase control)
- – Stable under 2 Ohms and 1 Ohm
- – Output lines
- – The DBES1000 only measures (27 x 11.2 x 4.6 cm)
SoundBooster DBES1000.1 Mono Amplifier 1000W RMS
Features:
CAR MONO BASS AMPLIFIER
1000W x 1RMS(1 OHM, 14.4)
600W x 1RMS(2 OHM,14.4)
400W x 1RMS(4 OHM,14.4)
Specification:
LED
Input Level:0.2-5 V
Frequency Response:10-220 Hz
LPF:40-220 Hz
SubSonic Filter (HPF):10-50 Hz
THD at 4Ohm load 30% Rated Power:<0.3%
S/N Ratio:>80dB
Best Efficiency @4ohm:>80%
Minimum Load:1 Ohm
Optional Remote
Low voltage protection:Yes, protect <8 V
ShortCircuit Test @ max power:Pass
Overheat protect temperature:Protect at 80/176F
Components & PCB:SMD parts/double side FR-4 pcb
2 RCA INPUT
*** Installation ***
We provide installation services, please ask for a free quote.
