Description

REDARC 12V or 24V 10A Chopper Relay – Latching – CR1224L

REDARC 12V or 24V 10A Chopper Relay – Latching – CR1224L. Latching ‘Chopper’ Relay that features 2 outputs to latch on or off from a push-button switch. Each output remains ON or OFF until the next input signal causes the outputs to swap. Ideal for fog light switches, rear demisters and any dash type switches that need to latch on from a momentary push. Can be used in conjunction with a Bi-Metallic switch to provide auto off directional motor control like electric windows. The supply must be protected by a fuse of suitable rating.

Features:

• 12/24V operation.
• 10A maximum current.
• Compact design.
• Standard relay base pinouts.
• 2 year warranty.

Specifications:

• Operating voltage: 12V / 24V.
• Max. Rated Output Current: 10A.

Dimensions:

• Height (mm): 30
• Width (mm): 31
• Depth/Length (mm): 81
• Weight (g): 90
