Description

REDARC 80W Monocrystalline Solar Panel – SMRP1080

REDARC 80W Monocrystalline Solar Panel – SMRP1080. Monocrystalline fixed panels are highly efficient with a robust design. A tempered glass coating and a sturdy aluminium frame ensure that our panels will withstand harsh road conditions and extreme weather conditions. Designed for a fixed installation, typically on the roof area of caravans, RV’s, motorhomes, as well as some camper trailer and 4×4 vehicle applications. Has anodised aluminium frame and tempered glass coating they are well suited for outdoor use and employ quality MC4 style connectors for easy installation. Fixed solar panels feature a weight improvement and smaller footprint design for their power output, effectively contributing to a lighter, smaller design with greater cell efficiency. Each panel is tested at time of manufacture to conform to CE standards, so you can be sure that the panel output is exactly as described in its specification.

Features:

• Monocrystalline cell construction.
• Anodised aluminium frame.
• Robust tempered glass coating.
• Quality MC4 connectors.
• Dimensions (mm): 740 x 590 x 35
• 2 year warranty.

Specifications:

• Solar cell type: Monocrystalline.
• Open circuit voltage: 22.56V.
• Frame or material: Anodized aluminium.
• Max. Power voltage: 18.8V.
• Short circuit current: 4.47A.
• Operating temperature: –40°C to +85°C.
• Cable length: 900mm.
• Max power current: 4.26A.
• Connector type: MC4-style.

Dimensions:

• Height (mm): 740
• Width (mm): 590
• Weight (kg) 4.8
