Description

REDARC 10A Solar Regulator – SRP0120

REDARC 10A Solar Regulator – SRP0120. A solar regulator to ensure power supplied from the solar panels are at the right voltage to charge your house/auxiliary batteries. Suitable for charging up to two separate battery banks. Used with the SMR range of solar panels.

Note: Battery default setting is AGM. Not compatible with Lithium (LiFePO4) batteries.

Features:

• Multi-stage charging.
• Dual battery outputs.
• LED indication.
• 2 year warranty.

Specifications:

• Current rating: 10A.
• Standby current: <4mA.
• System voltage: 12V/24V DC.
• Input voltage: 12V/24V.
• Max. Charging voltage: 14.8V/29.6V.
• Max. Rated output current: 10A.
• Dimensions:
  • Height (mm): 37
  • Width (mm): 76
  • Depth/Length (mm): 153
  • Weight (g): 240
