Description
Star Flat 16.2 – Designed & Engineered in Germany
Overview
The Top-of-the Line coaxial system of the Star Flat series is equipped with a 165mm woofer with coated Star-Flat paper cone and, in combination with the enormously powerful and at the same time space-saving internal high power ferrite magnet system, develops an above-average acoustic performance potential , The integrated titanium-coated polycarbonate tweeter is responsible for the transparent treble range. The installation depth remains extremely low thanks to Pro-Flat technology. The multi-part grille including Diamondcut logo and black-rubber coating makes for a chic appearance, the installation is absolutely no problem thanks to Euro DIN basket.
Features
- 2way coax system
- Multi-part protection grille including diamond cut logo
- Euro DIN basket for universal usage
- Low mounting depth due to Pro Flat technology
- Solid steel basket with low-tone structured coating
- Internal high power ferrite magnet system
- Dynamic foam surround for high efficiency
- Coated Star Flat cellulose cone (woofer)
- Woofer: coated cellulose
- Titanium coated polycarbonate
- Titanium-coated polycarbonate tweeter
Specifications
- 2 way coaxial system
- SOUND PRESSURE LEVEL 91 dB
- IMPEDANCE 4 ohms
- FREQUENCY RANGE 32 – 28000 Hz
- CROSSOVER FREQUENCIES 3400 Hz
- Woofer: 6.5 “
- OUTER DIAMETER Woofer: 196 mm
- CUTTING OUT Woofer: 143 mm
- MOUNTING DEPTH Woofer: 45 mm
- MOUNTING HIGHT Woofer: 19 mm
