Description
In ideal conditions you’ll enjoy up to 250km range with the new Energypack 800 and powerful Yamaha SyncDrive 85nm motor, so you’ll be able to ride every trail, every steep climb, every thrilling descent, again and again!
Trail technology
Proven Maestro rear suspension (160mm) and a powerful but compact SyncDrive Pro motor technology boost your capabilities on steep climbs and rugged descents.
Total control
RideControl Ergo 3 offers integrated, user-friendly button controls that are easy to use. The Giant E-bike App gives you tuning options and E-bike specific fitness tracking.
Long-lasting power
Climb steep mountains and enjoy fun descents all day long with the downtube-integrated EnergyPak with 800Wh of energy.
A 29-inch front wheel and 27.5-inch rear wheel work together to offer superior handling and agility on technical terrain. The updated frameset features new geometry with a shorter rear end and longer reach. New control units include RideControl Go, which is integrated into the top tube, and RideControl Ergo 3, attached to the handlebar near the grip. A new flip chip feature lets you adjust frame geometry for riding style and terrain.
- Energypak 800WH battery with 70-250km range depending on terrain
- RideControl GO, frame integrated LED display
- ALUXX SL-grade Aluminium frame 160mm travel with flip-chip adjustable geometry mated to Fox 38 Rhythm forks with 170mm travel
- Shimano CUES SL-6000 11 speed gearing
- Shimano Deore 4 piston hydraulic disc brakes
- Giant Contact Switch, dropper seat post
SIZING: (Rider height)
Small: 163-172cm
Medium: 171-180cm
Large: 179-188cm
X-Large: 187-198cm
BIKE SPECSFRAME ALUXX SL-grade Aluminium, Advanced Forged Composite Upper Rocker, 160mm Maestro suspension system, flip chip, UDH hanger 12x148mm thru-axle FORK Fox 38 Rhythm E-Tuned, 170mm travel, 44mm offset, GRIP damper, Boost Kabolt-X 110x15mm FRONT HUB Shimano MT410 Boost, Center-Lock REAR HUB Shimano MT410 Boost, Center-Lock SPOKES Sapim E-Lite e-bike optimized RIMS Giant AM 29″[F] 27.5″[R], Tubeless ready, 30mm inner width INNER TUBES Presta valve FRONT TYRE Maxxis Minion DHF 29×2.6″ foldable, Tubeless, EXO+, 3C MaxxTerra REAR TYRE Maxxis High Roller II 27.5×2.5″ foldable, Tubeless, DoubleDown, 3C MaxxTerra Compound CRANKSET Praxis Wave™ 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set CHAINRINGS Praxis Wave 36T Cold Forged 4130 premium steel BOTTOM BRACKET N/A SHIFT LEVERS Shimano CUES, SL-6000, 1×11 speed FRONT DERAILLEUR MRP HD2 co-moulded chain guide REAR DERAILLEUR Shimano CUES, U6000, Shadow+ CASSETTE Shimano Cues LinkGlide, CS-LG400-11, 11-50T, 11-speed CHAIN Shimano LinkGlide, CN-LG500 FRONT BRAKE Shimano Deore, BR-M6120, 4-piston, hydraulic disc, 220mm REAR BRAKE Shimano Deore, BR-M6120, 4-piston, hydraulic disc, 203mm HANDLEBARS Giant Contact Trail 35mm GRIPS Giant Tactal Pro-E, single lock-on STEM Giant Contact SL 35mm SADDLE Velo VL3594 SEATPOST Giant Contact Switch, dropper, 30.9mm SEAT BINDER Alloy clamp PEDALS N/A MOTOR SyncDrive Pro 2, 85Nm, powered by Yamaha CONTROLLER RideControl Ergo 3, grip integrated. RideControl GO, frame integrated LED displayANT+ Wireless display compatible BATTERY EnergyPak Smart 800Wh EnergyPak Plus range extender compatible. Torx 25 Battery Lock with built-in Torque limiter. EnergyPak 6A smart charger EXTRAS Tubeless kit (liquid, valves, levers, manual, tool) |
* Specifications are subject to change without notice
