Description
Innovative combination of shunt and tank level module. SC502T is a high precision combo shunt for PICO battery monitor with 2x voltage, 2x temperature and 1x current sensor up to 500A for up to 75V systems.
It can be used for monitoring current draw of heavy consumers (inverters, bow and stern thrusters, anchor winches) and current generators (shore power chargers and solar panels). Additionally, it allows monitoring tanks for fuel, fresh and grey water.
| TECHNICAL INFORMATION | |
| Operating | |
| Power source voltage range | 6 – 35 V |
| Temparature range | -20 – +70 °C |
| Power consumption at 12 V | |
| Operating | 0.8 mA |
| Current measuring range | |
| Per channel | 0,1 – 320 A |
| Accuracy | ± 0,6 % |
| Resolution | 0,01 A |
| Sampling rate | 100 ms |
| Maximal current | |
| Continuous | 300 A |
| Peak current (<1 min) | 400 A |
| Peak current (<5 min) | 700 A |
| Voltage drop at 300 A | 50 mV |
| Maximal voltage on connections | 35 V |
| Voltage inputs | |
| Range | 0 – 75 V |
| Resolution | 1 mV |
| Accuracy | ± 0,2 % |
| Sampling rate | 100 ms |
| Resistance inputs | |
| Range | -15 – +80 °C |
| Accuracy (-10 – 60 °C, 14 – 140 °F) | ± 3,0% |
| Temparature sensor – NTC 10k | |
| Range | -15 – +80 °C |
| Accuracy (-10 – 60 °C, 14 – 140 °F) | ± 3,0% |
| Connectivity | Up to |
| Batteries | 1 |
| Temparatu” | |
